Purpose:
The hammer mill is designed for grinding wood chips, chips or other biomass with a fraction size up to 50 mm. In the production of pellets / briquettes, a module is needed before pressing in order to provide a uniform input material for the pellet / briquette press, which is important for the capacity, consumption and depreciation of the machine. The hammer mill allows the highest quality processing / grinding / of wood materials with minimal maintenance and low operating costs.CopyrightScandinavian moss paintingsInterior Design
| Indicator |
Measure |
Value |
|---|---|---|
| Length |
mm |
1350 |
| Width |
mm |
1120 |
| Height |
mm |
1590 |
| Power of electric motor |
kW |
37 |
| Machine weight |
kg |
660 |
| Rotor diameter |
mm |
400 |
| Rotor length |
mm |
750 |
| Number of hammers on the shaft |
no. |
56 |
| Rotor speed |
min-1 |
3000 |
| Sieve dimensions |
mm |
From f4 to f15 |
| Productivity |
kg / h |
1000** |
| Material input dimensions |
mm |
350 x 200 |
| Electric power supply |
U, Hz, P |
380V, 50Hz, P = 37kW |
| Humidity of the material |
% |
max 35 |
| Max. Dimensions of the material |
LxWxH (mm) |
30x30x50 |
** Productivity up to P = 400kg / h at raw material humidity up to 35%
